Our customer? Text 0483 903 020 and Liv, our support assistant, will help you work through it. Thinking about a battery in the Northern Rivers NSW? Our own electricians install and look after Sungrow, SolaX and Tesla batteries from Tweed Heads to Evans Head and Lismore: see the towns we cover. We install in the Northern Rivers only.
Short answer. The SBH is Sungrow’s larger-module high-voltage lithium (LFP) battery, built from 5.0 kWh modules. You watch it in the iSolarCloud app. On the front, five SOC bars show the charge (each bar is 20%) and a status light shows its health: steady blue is normal, red means an alarm or fault. Read the lights from where you stand, and call us if you see red.
Safety first. Never open a switchboard, remove a cover from your battery or inverter, or touch any wiring. Anything beyond the app, a light you can read from a safe distance, or your own router is a job for a licensed electrician. If you see smoke, smell burning, hear arcing or see water on or near the unit: keep everyone away, switch off at your main switch only if it is safe to do so, and call 000 if there is any fire or smoke.

Sungrow’s SBH range is a floor-standing stack of 5.0 kWh modules: from two modules (10 kWh) up to eight (40 kWh), with up to four stacks able to run in parallel on a compatible Sungrow hybrid inverter. It is rated IP55 for indoor or outdoor mounting, and Sungrow lists a 10-year warranty on the datasheet (conditions are in its warranty letter). Which size you have comes from the design we did from your power bills.
This is Sungrow’s own description for the SBH, in plain English.
As with the SBR, the Sungrow hybrid inverter decides when the battery charges and discharges. Sungrow’s inverter manual describes a Backup Mode (off by default) with a reserved battery level kept for a blackout, plus battery discharge times and forced-charge times. These settings differ between inverter models and app versions, so tell us what you want and we set it. See Backup Reserve and battery modes.
Updates are done through the app while the system is grid-connected, and nothing should be changed during one, per Sungrow. We handle updates for systems we install. The fast blinking blue light can simply mean an update or calibration is running, so do not interrupt it.
The batteries we install carry a 10-year battery warranty, with Sungrow’s conditions in its warranty letter. Our 25-year workmanship warranty covers our installation work only; equipment is covered by Sungrow. See where to find your warranty documents.
Alarms and faults appear in iSolarCloud with a code. Sungrow’s troubleshooting list covers things like data not refreshing yet (wait 5 to 10 minutes), communication problems and temperature limits (the batteries charge between 0 and 55 degrees C and discharge between minus 20 and 55 degrees C, so a very cold or hot spot can pause charging). Persistent alarms need the installer.
If you ever need to isolate the system, follow the shutdown procedure on the label on your inverter, in the order shown.
The two ranges look alike and run the same way, but SBH modules are 5.0 kWh (against 3.2 kWh for SBR) and handle up to 50 A (against 30 A). Our full comparison: Sungrow SBR vs SBH: what is the difference?
Read more: Sungrow batteries from Sun Connect Solar and Sungrow, Solax and Tesla batteries
If we installed your system, call us on 0483 903 020. Our service help for existing customers is free: we start by working through it with you by phone. If you are not yet a customer, a service call is $250 + GST, which covers one hour on site within 20 km of Mullumbimby; travel further out is quoted separately. Contact us or call 0483 903 020 (open 24 hours, 7 days). We do not repair systems we did not install.
The battery has five SOC bars, each worth 20%: no bars is empty, one bar is up to 20%, and five bars is above 80%. A steady SOC light means normal; a blinking one means it is charging or discharging.
Slow blinking blue (about once a second) means the battery is booting or on standby. Fast blinking blue (every half second) means it is being upgraded, tested or calibrated. Neither is a fault.
Sungrow lists slow blinking red as a battery system alarm and steady red as a battery system fault. Note the code in iSolarCloud and call us.
No. Both are modular high-voltage lithium iron phosphate batteries, but SBH modules are larger (5.0 kWh against 3.2 kWh) and carry more current. See our SBR vs SBH comparison.
Sungrow says a stack takes two to eight modules and a system can run up to four stacks in parallel, but adding modules has to follow Sungrow’s procedure, including matching the charge level. Call us first; adding modules without it can affect the warranty.
